Prolific PL2303GT USB to RS232 Serial Converter Adapter PCB Module USB RS232 Serial Adapter Windows Mac Linux Supported
- Product Description
-
Converts a USB port to RS232 serial ports.
Designed with original Prolific PL2303GT
The module is powered from the host USB port.
Pinout provided are： GND, DCD, RXD, TXD, DTR, CTS, RTS, DSR, RI, VDD(5V)
With black or transparent housing.
Operating temperature range -40oC to +85oC.Driver needed:
Download the Windows 7 to Windows 11 and Windows Server driver installer from the Prolific.com.tw Website.
About PL2303GT
PL2303GT USB to RS232 Serial Bridge Controller With Built-in RS232 Transceiver
USB Interface
* Single-chip USB to RS232 asynchronous serial data transfer interface.
* Fully Compliant with USB 2.0 specification (Full-Speed Mode).
* UHCI/OHCI (USB 1.1), EHCI (USB 2.0), xHCI (USB 3.1) Host Controller Compatible.
* Royalty-free USB to Virtual Com Port (VCP) drivers for Windows, Mac, Linux, and Android.
* Highly integrated USB 1.1 FS Transceiver. Integrated termination resistors and pull-up resistor to reduce PCB external components.
* Supports OTPROM (One-Time Programmable ROM) for USB device descriptors configuration. OTPROM can be programmed directly through USB port.
* Each IC has unique ID (for Serial Number).
* Supports bus-power, self-power and high-power USB device configuration.
* Supports Windows USB Selective Suspend (Remote Wakeup enabled).
* Supports 3.3V VBUS voltage operation
UART Interface (RS232)
* Built-in RS232 Transceiver:
>> Meets EIA/TIA-232F standards with 5.0V power supply
>> Guaranteed 1000kbps transmission rate under loading
>> Three RS232 Drivers design
>> Five RS232 Receivers (always active)
>> Latch-up free
* RS232 Serial Port Output Interface:
>> Full UART RS232 interface pins (TXD, RXD, RTS, CTS, DTR, DSR, DCD, and RI)
>> Flexible baud rate support up to 1Mbps
>> 5, 6, 7 or 8 data bits
>> Odd, Even, Mark, Space, None parity mode
>> One, one and a half, or two stop bits
>> Hardware and Software Flow Control
>> Provides RS232 shutdown indicator pin
* 1024-byte bi-directional data FIFO buffers (768-byte receive/256-byte transmit) for faster data troughput.
* Configurable Transmit (TX) and Receive (RX) LED pins using configurable GPIO pins.
